An advanced fabric for bulletproof and stab-proof body armor
The Aerorate Protection Aramid UD Fabrics can meet three types of requirements:
bulletproof, stab-proof, and dual protection (bulletproof and stab-proof), complying with international standards like NIJ 0101.6, NIJ 0115.00, HOSDB 2007, VPAM BSW 2006, etc.
They provide an extraordinary softness and lightweight for our soft armor products, translating to a high level of comfort for the wearer.
| Main Material | Aramid | |||
Product ID | APB-210 | APS-230 | APBS-215 | APB-165 |
| Test Standard | NIJ 0101.06 | NIJ 0115.00 | NIJ 0101.06 NIJ 0115.00 | NIJ 0101.06 |
Areal Density (kg/㎡) | 210±5 | 230±5 | 215±5 | 165±5 |
| Size (m) | 1.6×3.2 | 1.6×3.2 | 1.6×3.2 | 1.6×3.2 |
| Thinness (mm) | 0.15 | 0.16 | 0.15 | 0.12 |
| Application | Bulletproof | Stab-proof | Bullet & Stab-proof | Anti-trauma |
| Structure | Two orthogonal unidirectional laminated materials at 0°/90°, Aerorate Protection patented-formula resin adhesive | |||
| Warranty | 5 Years | |||
| Applied this Aramid UD Fabric as raw material, our soft panel designs seamlessly integrate into our vest series, consisting of Full Protection, Concealable, Quick-Release, Tactical, Female, Waistcoat, and other variants; Backpack, Suitcase, and other gears. Each design provides a tailored fit, increased maneuverability, and higher cost-effectiveness. | ||||
1. Remove the functional panels from the carrier.
2. Use a soft-bristled brush or cloth to wipe the surface of the panel, avoid using cleaners that could damage the surface of the panel.
3. Dry clean, handwash or machine wash the carrier, avoid using any bleach.
4. Lay flat the carrier, air dry or humble dry it. We suggest that you prepare another carrier in case the cleaning causes delay.
5. Insert the panel back into the carrier.
To know more details, please click here: Care Instruction: How to clean and store your armor?
1. Ensure that your vest/plate carrier has the necessary pockets or compartments designed to hold ballistic plates. Most of them have front and back pockets for this purpose, while some have side pockets, too.
2. Start by unfastening any straps or closures on the vest/carrier to access the pockets.
3. Take the ballistic plates and orient them correctly. Typically, the curved side of the plate, instead of the "STRIKE FACE" side, should face your body for better ergonomics and fit.
4. Slide the plates into the appropriate pockets. Make sure they are centered and aligned properly.
5. Once the plates are inserted, secure them in place by fastening any straps, Velcro closures, or buckles provided by the vest/carrier. Ensure that the plates are snugly held in position and do not shift around.
6. Adjust the straps to achieve a comfortable and secure fit. The vest/carrier should be snug but not overly tight, allowing for freedom of movement while maintaining proper protection.
To know more details, please click here: Use Instruction: How to insert and remove the ballistic plate?
All our products are tested to NIJ standards by third party professional laboratory, giving you confidence in the quality and protection of our products. The claimed armor materials are inspected and graded by our lab technicians to ensure they meet our strict quality criteria. Please Contact Us to have a copy of test report.
All of our armors come with a 5-year warranty and are tested to NIJ standards giving you confidence in the quality and protection of our products.
